Description
Generac 5000W Diesel Portable Generator – XD5000E | Model G006864
The Generac XD5000E delivers dependable diesel-powered performance for demanding environments. Featuring a 435cc Yanmar LW Series engine and True Power™ Technology for clean output, this unit is engineered for efficiency, long runtime, and industrial-grade reliability.
- Diesel Power & Efficiency: Yanmar 435cc air-cooled engine meets Tier IV standards and offers extended life and fuel savings over gas models.
- Clean, Safe Power: True Power™ Technology ensures <6% Total Harmonic Distortion (THD) for safe use with electronics and tools.
- Extended Runtime: 12-gallon fuel tank allows up to 32.4 hours of use at 50% load.
- Cold Weather Features: Compression release lever and primer bulb improve starting in cold climates.
- Engine Protection: Low Oil Pressure Shutdown protects engine during extended use.
- Durable Construction: Fully welded 1¼” steel tube frame with lifting eye for secure transport.
- Electric Start: Single-touch electric start (battery not included) with hour meter and recoil backup.
- Outlet Options: Includes 120V GFCI duplex, 120/240V twist-lock, and 120V twist-lock for flexible use.
Specifications Table
| Attribute | Value |
|---|---|
| Model Number | G006864 |
| Max Wattage | 5000W |
| Engine | Yanmar LW Series 435cc (Diesel) |
| Fuel Tank Capacity | 12 gallons |
| Run Time @ 50% Load | Up to 32.4 hours |
| THD | <6% |
| Start Type | Electric + Recoil backup |
| Voltage | 120/240V switchable |
| Frame | Fully welded 1¼” steel tube cradle |
| Weight | 252 lbs (approximate) |
| Dimensions (LxWxH) | 33.8″ x 22.5″ x 25.8″ |
| Warranty | 2-Year Limited |
